MITSUBISHI MV2400R
Review the machine configuration, technical highlights, sourcing notes, and RFQ preparation details before requesting a quote.
Gallery
MITSUBISHI MV2400R
MITSUBISHI MV2400R
MITSUBISHI MV2400R
NewEDM
MITSUBISHI / EDM Machines
MV2400R
Precision wire EDM for tool and die, medical, and aerospace components requiring tight tolerances and fine surface finishes on conductive materials.
Year
2025
Hours
0 h
Location
Bucharest showroom
Availability
Factory order / 14-18 weeks
Technical highlights
Machine capability snapshot
RFQ-ready data
Travel: 600 x 400 x 310 mmWire diameter: 0.10-0.30 mmMax taper: +/-45 degControl: Mitsubishi M800
Specification table
Readable technical data
GroupSpecificationValue
CapacityAxis travel (X/Y/Z)600 x 400 x 310 mm
CapacityMax workpiece weight1,000 kg
CapacityWire diameter range0.10-0.30 mm
PerformanceMax taper angle+/-45 deg
PerformanceSurface finishRa <= 0.18 um
ControlCNC controlMitsubishi M800
Logistics & sourcing notes
- Shipped with dielectric oil system and filtration unit.
- Rigging: 4-point lift; approx. 4,200 kg.
- Installation: Requires 400V 3-phase and deionized water supply.
Recommended buyer questions
- 01Verify floor space: 3.2 x 2.8 m footprint.
- 02Confirm 400V 3-phase power and deionized water supply.
- 03Check wire spool compatibility (0.10-0.30 mm).
- 04Arrange rigging for 4,200 kg machine weight.
